AVMatrix PTZ Camera EAGLE P20A

AVMatrix Eagle P20A – 20X AI Auto-Tracking FHD PTZ Camera. Intelligent human tracking with selectable shot framing, 20× optical zoom, simultaneous HDMI + 3G-SDI + USB + IP streaming, ONVIF/VISCA/Pelco control, ceiling/wall/tripod mount.

The AVMatrix Eagle P20A is a powerful 20X optical zoom AI-tracking PTZ camera designed for hands-free, professional-grade live production. Using advanced deep-learning algorithms, it automatically detects and smoothly tracks presenters with three intelligent shot modes (full-body, waist-up, close-up) – ideal for lecture capture, houses of worship, conference rooms, and broadcast studios without needing a dedicated operator.

Built around a 1/2.8″ Sony CMOS sensor, while simultaneously outputting HDMI, 3G-SDI, USB 2.0 (UVC/UAC), and IP streaming (RTSP/RTMP/SRT/ONVIF). Full control compatibility includes VISCA-over-IP, ONVIF, Pelco-D/P. Quiet, high-precision pan/tilt mechanics (±170° pan, -30°/+90° tilt) with 255 presets and multiple mounting options (ceiling, wall, tripod) make installation flexible and operation silent. 3.5mm audio input embeds line/mic level sound into every output.

Key Features

• AI Human Tracking – Auto-detects and follows talent with selectable framing (full / waist / close-up)
• 20X Optical + 16X Digital Zoom – 1080p60 clarity from wide to tight shots
• Simultaneous Outputs – HDMI + 3G-SDI + USB 2.0 + IP streaming
• Control Protocols – ONVIF, VISCA over IP, Pelco-D/P, optional NDI control
• Silent & Precise PTZ – ±170° pan, -30°/+90° tilt, 255 presets
• Flexible Installation – Ceiling, wall, tripod mounts included
• Audio Embedding – 3.5mm line/mic input into all streams
