Datavideo HDR-90

  • Free transport
SKU: 2600-0290

The Datavideo HDR-90 is a rackmount video recorder with LCD that controls and manages 10-bit ProRes data files with a 4:2:2 aspect ratio. The HDR-90 supports UHD 12G SDI I/O and 4K HDMI input/output, as well as DVIP (Ethernet), GPI and RS-232.

More information

3 529 € with VAT 2 916.53 € without VAT
Add to Compare Price history
Availability
14-30 days
SKU:
2600-0290
Add to Compare Price history

Datavideo HDR-70

2 659 €without VAT 2 197.52 €

Datavideo HDR-60

2 659 €without VAT 2 197.52 €

Datavideo HDR-1

769 €without VAT 635.54 €

Datavideo HDR-80 4K ProRes Video Recorder

In stock 1 pcs3 529 €without VAT 2 916.53 €
Product description SPECIFICATIONS PACKAGE CONTENT

Product description

The Datavideo HDR-90 is a rackmount video recorder with LCD that controls and manages 10-bit ProRes data files with a 4:2:2 aspect ratio. The HDR-90 supports UHD 12G SDI I/O and 4K HDMI input/output, as well as DVIP (Ethernet), GPI and RS-232.

PACKAGE CONTENT

  • 1 x HDR-90 Main Unit
  • 1 x Adaptor + AC Cord
  • 2 x 2.5” Removable HDD/SSD Enclosure
  • 8 x Screws for 2.5 Removable HDD/SSD Enclosure
  • 2 x Blank Label
  • 1 x SATA to USB Cable
  • 2 x Ear mount kit
  • 6 x M4 x 8mm screws

SPECIFICATIONS

  • Video standard UHD and HD
    Video format
    2160p 23.98 / 24/25 / 29.97 / 30/50 / 59.94 / 60 Hz
    1080p 23.98 / 24/25 / 29.97 / 30/50 / 59.94 / 60 Hz
    1080i 50 / 59.94 / 60 Hz
    720p 50 / 59.94 / 60 Hz
  • Supported input video signal
    1x 3G / 12G SDI
    3x 3G-SDI
    1x HDMI 2.0
    1x HDMI 1.4
  • Monitor / Playback Output
    1x 3G / 12G SDI
    1x HDMI 2.0
    3x HDMI 1.4
  • Analog Audio Input / Output
    2x balanced XLR (stereo pair)
    2x balanced XLR (stereo pair)
  • Built-in Audio
    SDI Input / Output (8CH)
    HDMI Input / Output (8CH)
  • Storage Media 2.5" SSD, USB Flash, SD Card
    Estimated Recording Time (min. Per 10 GB)
    SD: 90 (proxy), 39 (LT), 27 (default), 18 (HQ)
    HD: 27 (proxy), 11.5 (LT), 8 (default), 5.5 (HQ)
    3G: 13 (proxy), 6 (LT), 4 (default), 2.5 (HQ)
  • Recording media SSD, USB, SD card
    File system exFAT
  • Recorded file format QuickTime .MOV
  • Video recording bit rate / color sampling
    ProRes HQ 4:2:2
    ProRes QuickTime 4:2:2
    ProRes LT 4:2:2
    ProRes Proxy 4:2: 2
  • Audio Recording Format
    Uncompressed PCM
    Sample Rate 48 kHz 24 bit
  • Time Code Input/Output Yes
  • External Sync / Genlock Black Burst & Tri-level with loop-through
  • Rack Mounting 1RU
  • Operating Temperature 0°C - 40°C
  • Dimensions 288 x 481 x 49 mm
  • Weight: 4 kg
Parameters

Parameters

Manufacturer: Datavideo
Category: Studio recorders

Main parameters

VersionRack
Format/CodecProRes · MOV
Supported resolutionUHD/50p, 60p · UHD/24p, 25p, 30p · 1080/50p, 60p · 1080/24p, 25p, 30p · 1080/50i, 60i · 720/50p, 60p
InputHDMI · 12G SDI · 6G SDI · 3G SDI · SDI
Recording mediumHDD · SSD · SD card

Other parameters

Other featuresSDI Loop
Power supply typeSource
