Decimator Design MD-DUCC

The MD-DUCC is the latest converter to come from Decimator Design. A low cost converter to convert ANY video format/frame rate to ANY other video format/frame rate!

The MD-DUCC is the latest converter to come from Decimator Design. A low cost converter to convert ANY video format/frame rate to ANY other video format/frame rate!

Features:

• Auto detects 3G, HD or SD (26 formats in total)
• Full 10-bit data path and multipoint interpolation
• Professional motion-adaptive de-interlacing
• True Down Up Cross Conversion, allowing the conversion between any of the supported formats. Simply select the output format you require, no  matter what the input format is
• Complete 16:9, 14:9 and 4;3 Aspect Ratio conversion support, with individual selection for HD to HD, HD to SD, SD to HD nad SD to SD conversions
• Full 16-Channel Audio Metering
• Adjustable Graticules Generator
• Text Overlays
• HDMI Output
• Selectable analogue video with 3 x CVBS / YPbPr / RGB / CVBS & YC
• 2 x (3G/HD/SD)-SDI 10-bit outputs with audio from input automatically delayed and passed
• GPI on RJ-45 for Tallies
• 3G/HD/SD-SDI Active Loop-Through Output
• De-Embedded audio can be output on 2 x RCA connectors as either AES or Analogue with adjustable analogue audio level
• LEDs for status and buttons for basic configuration
• USB port for control and firmware updates
• Locking DC Power Socket
• The following is also included with the unit: power supply, HDMI cable, USB cable and Mounting Bracket
